AS85049/10-12N

View detailed technical data, stock status, and sourcing information for: AS85049/10-12N
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for part AS85049/10-12N to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5935 Electrical Connectors

National Stock Number

5935-01-165-3039

Item Name Code

67169

Assigment Date

10/27/1983 (42 years ago)

right-hand thread direction, unable to decode seal material, 2b thread class, 0.858 inches maximum overall diameter, gland nut furnished items

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Thread Class: 2b
Thread Direction: right-hand
Seal Material: unable to decode
Furnished Items: gland nut
Overall Diameter: 0.858 inches maximum
Seal Type: preformed packing
Size Designation: 12 and 12s
Mounting Facility Type And Quantity: 1 threaded coupling
Thread Quantity Per Inch: 20
Nominal Thread Size: 0.750 inches
Material: aluminum alloy
Surface Treatment: cadmium
Style Designator: straight type
Test Data Document: "81349-mil-c-85049 specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.)."
Thread Series Designator: unef
Specification/Standard Data: 81349-mil-c-85049/10 government specification

Replaces National Stock Numbers

Below is a list of NSNs that have been officially superseded by this NSN:

NSN	Name	Date
5935-01-067-7283	No Name Available	05/21/2019

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
AS85049/10-12N	Electrical Connector Backshell
M85049/10-12N	Electrical Connector Backshell
M85049/10-12W	Electrical Connector Backshell
MS3437A12N	Electrical Connector Backshell

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5935-01-165-3039?

The FSCG of the NSN 5935-01-165-3039 is 5935

Does the NSN 5935-01-165-3039 have a Schedule B code assigned?

Yes, the Schedule B code is 8548900100

Does NSN 5935-01-165-3039 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5935-01-165-3039 contain precious materials?

Item does not contain precious metal.

Does NSN 5935-01-165-3039 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 5935-01-165-3039 was assigned to the Federal Catalog?

It was assigned 42 years ago, on Thu, Oct 27, 1983
