RER45F4R02R

View detailed technical data, stock status, and sourcing information for: RER45F4R02R
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for part RER45F4R02R to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5905 Resistor

National Stock Number

5905-00-506-6608

Item Name Code

37404

Assigment Date

07/20/1974 (52 years ago)

4.020 ohms electrical resistance, 275.0 ambient temp in deg celsius at zero percent rated power, -1.000 to 1.000 resistance tolerance in percent, -50.0 to 50.0 temp coefficient of resistance in ppm per deg celsius, -55.0 to 275.0 temp range of temp coefficient in deg celsius

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Temp Coefficient Of Resistance In Ppm Per Deg Celsius: -50.0 to 50.0
Electrical Resistance: 4.020 ohms
Resistance Tolerance In Percent: -1.000 to 1.000
Ambient Temp In Deg Celsius At Zero Percent Rated Power: 275.0
Temp Range Of Temp Coefficient In Deg Celsius: -55.0 to 275.0
Reactance Characteristic: noninductive
Reliability Indicator: established
Reliability Failure Rate Level In Percent: 0.010
Terminal Length: 0.312 inches nominal
Body Length: 0.750 inches nominal
Body Width: 0.438 inches nominal
Body Height: 0.406 inches nominal
Distance Between Centerlines Of Mounting Facilities Parallel To Body Length: 0.562 inches nominal
Power Dissipation Rating In Watts: 6.000 free air
Ambient Temp At Full Rated Power: 25.0 celsius
Inclosure Type: encased
Mounting Hole Size: 0.094 inches nominal
Terminal Type: tab, solder lug
Style Designator: axial terminal (s)
Test Data Document: "81349-mil-r-39009 specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.)."
Specification/Standard Data: 81349-mil-r-39009/2 government specification

Replaces National Stock Numbers

Below is a list of NSNs that have been officially superseded by this NSN:

NSN	Name	Date
5905-01-047-2847	No Name Available	02/05/2025

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
127-61335-13	Resistor,fixed,wire Wound,nonind
127-61338-13	Resistor,fixed,wire Wound,nonind
NH-10-4.02OHMSPORM1%	Resistor,fixed,wire Wound,nonind
RER45F4R02M	Resistor,fixed,wire Wound,nonind
RER45F4R02R	Resistor,fixed,wire Wound,nonind

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5905-00-506-6608?

The FSCG of the NSN 5905-00-506-6608 is 5905

Does the NSN 5905-00-506-6608 have a Schedule B code assigned?

Yes, the Schedule B code is 8533390080

Does NSN 5905-00-506-6608 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5905-00-506-6608 contain precious materials?

Precious metal content is unknown

Does NSN 5905-00-506-6608 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5905-00-506-6608 was assigned to the Federal Catalog?

It was assigned 52 years ago, on Sat, Jul 20, 1974
