5935-00-007-9213

Find complete technical information, availability, and procurement data for: 5935-00-007-9213
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5935-00-007-9213 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5935 Electrical Connectors

National Stock Number

5935-00-007-9213

Item Name Code

15091

Assigment Date

07/14/1972 (54 years ago)

An adapter with electrical contacts which provides facilities for joining two or more electrical connectors, whose design or function will not normally warrant their junction. It is not designed for permanent attachment to a cable, cord, coaxial line, or wire. The physical shape of an electrical connector should not be the determining factor of its name. Tee, angle, straight, and y-shaped adapters are all adapter, connector. Excludes:adapter, connector to lampbase; adapter, lampholder to connector; adapter (1), cable clamp to connector; and adapter, lampholder. For items designed as a mechanical connection between an electrical conduit and an electrical connector, see adapter (1), electrical conduit.

4.790 inches maximum overall length, 0.860 inches nominal overall height, 0.567 inches nominal overall width, moisture resistant and vibration resistant environmental protection, 0.128 inches nominal unthreaded mounting hole diameter

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Overall Length: 4.790 inches maximum
Overall Height: 0.860 inches nominal
Overall Width: 0.567 inches nominal
Environmental Protection: moisture resistant and vibration resistant
Unthreaded Mounting Hole Diameter: 0.128 inches nominal
Distance Between Mounting Facility Centers: 4.523 inches minimum and 4.537 inches maximum
Mating End Quantity: 1
Contact Position Arrangement Style: 2 rows of contacts non-inserted board single mating end
Contact Removability: nonremovable single mating end single contact grouping
Polarization Method: mating end
Contact Material: copper alloy 210 single mating end single contact grouping
Contact Surface Treatment: gold single mating end single contact grouping
Insert Material: plastic diallyl phthalate single mating end
Contact Surface Treatment Document And Classification: mil-g-45204,ty 2,cl 1 mil spec single treatment response single mating end single contact grouping
Contact Material Document And Classification: mil-c-21768 mil spec single material response single mating end single contact grouping
Insert Material Document And Classification: mil-m-14,ty sdg-f mil spec single material response or mil-p-19833,ty gdi-30f mil spec single material response single mating end
Included Contact Quantity: 41 single mating end single contact grouping
Included Contact Type: flat pin single mating end single contact grouping
Precious Material And Location: contact surface gold
Precious Material And Weight: 0.041 gold grains, troy
Precious Material: gold
Test Data Document: "81349-mil-c-21097 specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.)."
Specification/Standard Data: 81349-m-c-21097/14 government specification

Replaces National Stock Numbers

Below is a list of NSNs that have been officially superseded by this NSN:

NSN	Name	Date
5935-00-068-0891	No Name Available	08/01/2007

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
3-582152-5	Connector Adapter
582843-6	Connector Adapter
70A0127	Connector Adapter
M21097/14-13	Connector Adapter
MIL-DTL-21097/14	Connector Adapter
MILC21097-14	Connector Adapter

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5935-00-007-9213?

The FSCG of the NSN 5935-00-007-9213 is 5935

Does the NSN 5935-00-007-9213 have a Schedule B code assigned?

Yes, the Schedule B code is 8548900100

Does NSN 5935-00-007-9213 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5935-00-007-9213 contain precious materials?

Item contains gold.

Does NSN 5935-00-007-9213 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 5935-00-007-9213 was assigned to the Federal Catalog?

It was assigned 54 years ago, on Fri, Jul 14, 1972
