5930-01-037-6221

Find complete technical information, availability, and procurement data for: 5930-01-037-6221
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5930-01-037-6221 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5930 Switches

National Stock Number

5930-01-037-6221

Item Name Code

02134

Assigment Date

03/21/1977 (49 years ago)

A switch actuated by a definite angular rotation of the switch shaft about its axis. It consists of a body,switch and a control,rotary switch. For items having rated actuation travel and pressure characteristics, see switch,sensitive. Excludes relay,rotary; switch,stepping; and switch,telephone (as modified).

2.183 inches nominal overall length, explosion proof hazardous locations/environmental protection, 0.250 inches nominal single actuator first flat length, 0.312 inches nominal single mounting facility thread length, 2a single mounting facility thread class

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Thread Class: 2a single mounting facility
Thread Length: 0.312 inches nominal single mounting facility
Hazardous Locations/Environmental Protection: explosion proof
Overall Length: 2.183 inches nominal
First Flat Length: 0.250 inches nominal single actuator
Flat Height: 0.094 inches nominal single actuator
Shaft Diameter: 0.125 inches nominal single actuator
Shaft Length: 0.375 inches nominal single actuator
Nonturn Device Radius: 0.260 inches nominal at 3:00 o'clock
Individual Section Quantity: 3
Nonturn Device Type: tab at 3:00 o'clock
End Item Identification: virginia class cgn (41), tarawa class lha, yellowstone class ad-41, wasp class lhd, oliver perry class ffg, forrestal class cv, nimitz class cvn. nuclear power plants. cvn 68 class reactor fill auxiliary system.
Switch Contact Basic Design: nonpile-up symmetrical
Pole Quantity: 1 each section rear
Throw Quantity: 3 each section rear
Mounting Method: threaded bushing single mounting facility
Nominal Thread Size: 0.250 inches single mounting facility
Contact Voltage Rating In Volts: 115.0 ac at sea level
Contact Voltage Rating In Volts: 28.0 dc at sea level
Switch Actuator Indexing Position Quantity: 3 single actuator
Shaft Type: round, flatted single actuator
Criticality Code Justification: feat
Terminal Type: printed circuit
Contact Switching Action: breaks before makes each section rear
Switch Actuator Positioning Increment: 30.0 degrees single actuator
Switch Actuator Stop Device Type: fixed stop single actuator
Contact Load Current Rating: 250.0 milliamperes resistive load and 20.0 milliamperes inductive load dc at sea level
Contact Load Current Rating: 250.0 milliamperes resistive load and 50.0 milliamperes inductive load ac at sea level
Special Features: weapon system essential
Style Designator: tap, circular, bushing mount
Thread Series Designator: unef single mounting facility

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
09YY23624	Rotary Switch
9-YY-23624	Rotary Switch
PM-NTD-3W-NR-MS PIECE 21	Rotary Switch

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5930-01-037-6221?

The FSCG of the NSN 5930-01-037-6221 is 5930

Does the NSN 5930-01-037-6221 have a Schedule B code assigned?

Yes, the Schedule B code is 8536509020

Does NSN 5930-01-037-6221 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5930-01-037-6221 contain precious materials?

Precious metal content is unknown

Does NSN 5930-01-037-6221 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 5930-01-037-6221 was assigned to the Federal Catalog?

It was assigned 49 years ago, on Mon, Mar 21, 1977
