5905-00-006-5343
Find complete technical information, availability, and procurement data for: 5905-00-006-5343
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5905-00-006-5343 to receive an up to date pricing and availability quote by email.
An arrangement of multiple fixed resistive elements or discrete resistors permanently encased, encapsulated, or potted together, to form an inseparable unit. The resistive elements, consisting of a thin layer of conductive material deposited on or fused to an insulating base, usually are electrically connected to each other and may be arranged in any circuit configuration. Excludes:resistor, fixed (as modified); resistor assembly; resistor network, fixed-variable; and resistor set, matched.
-150.0 to 150.0 temp coefficient of resistance in ppm per deg celsius, 20.500 kilohms highest resistance value electrical resistance, -2.000 to 2.000 each resistor resistance tolerance in percent, 1.000 kilohms lowest resistance value electrical resistance, 10.000 kilohms intermediate resistance value electrical resistance
Product Characteristics
Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.
- Temp Coefficient Of Resistance In Ppm Per Deg Celsius
- -150.0 to 150.0
- Electrical Resistance
- 10.000 kilohms intermediate resistance value
- Electrical Resistance
- 1.000 kilohms lowest resistance value
- Electrical Resistance
- 20.500 kilohms highest resistance value
- Resistance Tolerance In Percent
- -2.000 to 2.000 each resistor
- Ambient Temp In Deg Celsius At Full Rated Power
- 70.0
- Ambient Temp In Deg Celsius At Zero Percent Rated Power
- 125.0
- Temp Range Of Temp Coefficient In Deg Celsius
- -55.0 to 125.0
- Inclosure Method
- encapsulated
- Terminal Quantity
- 14
- Terminal Type
- pin
- Reliability Indicator
- not established
- Terminal Length
- 0.100 inches minimum
- Body Length
- 0.760 inches maximum
- Body Width
- 0.290 inches maximum
- Body Height
- 0.200 inches maximum
- Schematic Diagram Designator
- series network
- Power Dissipation Rating In Watts
- 0.125 each resistor
- Identical Value Resistor Quantity
- 2 highest resistance value
- Identical Value Resistor Quantity
- 4 intermediate resistance value
- Identical Value Resistor Quantity
- 4 lowest resistance value
- Style Designator
- dual inline
Related Parts
This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:
| Part Number | Name |
|---|---|
| 006-509-001 | Film Fixed Resistor Network |
| 955201-1C | Film Fixed Resistor Network |
