4320-01-284-3467

Find complete technical information, availability, and procurement data for: 4320-01-284-3467
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 4320-01-284-3467 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Pumps and Compressors

Federal Supply Classification

4320 Power and Hand Pumps

National Stock Number

4320-01-284-3467

Item Name Code

14791

Assigment Date

08/23/1988 (37 years ago)

A specific electrical element or set of electrical elements that are connected together to form a fixed arrangement and used as a substitute load for terminating an electrical circuit. A dummy load contains all the essential electrical characteristics necessary to terminate the circuit but does not function in the same manner as the load which it replaces. Examples are resistors used to replace antennas, batteries, loudspeakers, or the like. Includes single port terminations of twin lead, coaxial and waveguide transmission lines as low power terminations of a section of a transmission system in a specified manner. Includes dummy loads when arranged in a group or bank. Excludes:power absorbers. See also load bank, electrical.

1800.0 revolutions per minute operating speed at rated capacity, piston pumping element type, 3500.0 pounds per square inch gage discharge pressure, lgm-30 minuteman end item identification, 10.6 gallons per minute maximum discharge flow rate

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Pumping Element Type: piston
End Item Identification: lgm-30 minuteman
Maximum Discharge Flow Rate: 10.6 gallons per minute
Discharge Pressure: 3500.0 pounds per square inch gage
Operating Speed At Rated Capacity: 1800.0 revolutions per minute
Pump Rotation Direction: counterclockwise
Reciprocating Stroke Type: variable
Criticality Code Justification: feat
Special Features: weapon system essential; weight 34 lbs

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
5122709-008-109	Axial Pistons Pump
L724395-523	Axial Pistons Pump
PVWJ-022-A1UV-LSAY-P-C2RNN-0523	Axial Pistons Pump

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 4320-01-284-3467?

The FSCG of the NSN 4320-01-284-3467 is 4320

Does the NSN 4320-01-284-3467 have a Schedule B code assigned?

Yes, the Schedule B code is 8413500070

Does NSN 4320-01-284-3467 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 4320-01-284-3467 contain precious materials?

Item does not contain precious metal.

Does NSN 4320-01-284-3467 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 4320-01-284-3467 was assigned to the Federal Catalog?

It was assigned 37 years ago, on Tue, Aug 23, 1988
