5342-00-489-3456

Find complete technical information, availability, and procurement data for: 5342-00-489-3456
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5342-00-489-3456 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Hardware and Abrasives

Federal Supply Classification

5342 Weapon System Hardware

National Stock Number

5342-00-489-3456

Item Name Code

53589

Assigment Date

01/01/1963 (63 years ago)

0.125 inches nominal flange thickness, 1.375 inches nominal distance between mounting hole centers, 8-32nc all threaded portions thread size, 1.813 inches nominal flange length, 1.813 inches nominal flange width

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Flange Thickness: 0.125 inches nominal
Thread Size: 8-32nc all threaded portions
Distance Between Mounting Hole Centers: 1.375 inches nominal
Flange Length: 1.813 inches nominal
Flange Width: 1.813 inches nominal
Shortest Distance Between Mounting Hole Centers: 1.375 inches nominal
Flange Mounting Hole Diameter: 0.196 inches nominal
Static Load Rating At Specified Deflection: 1 1/2 ld load at 3/64 in
Height: 1.500 inches nominal
Material: aluminum alloy overall
Surface Treatment: anodize overall
Style Designator: round spring compression four-hole flange

Replaces National Stock Numbers

Below is a list of NSNs that have been officially superseded by this NSN:

NSN	Name	Date
5340-00-200-4126	No Name Available	11/01/1968

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
344-1012P2	Weapon System Resilient Mount
770-3G	Weapon System Resilient Mount

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5342-00-489-3456?

The FSCG of the NSN 5342-00-489-3456 is 5342

Does the NSN 5342-00-489-3456 have a Schedule B code assigned?

Yes, the Schedule B code is 8710000090

Does NSN 5342-00-489-3456 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5342-00-489-3456 contain precious materials?

Item does not contain precious metal.

Does NSN 5342-00-489-3456 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5342-00-489-3456 was assigned to the Federal Catalog?

It was assigned 63 years ago, on Tue, Jan 1, 1963
