MV2101G

View detailed technical data, stock status, and sourcing information for: MV2101G
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for part MV2101G to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5961 Semiconductor Devices and Associated Hardware

National Stock Number

5961-00-434-3024

Item Name Code

20589

Assigment Date

05/26/1974 (51 years ago)

0.210 inches maximum overall height, 0.205 inches maximum overall length, 0.500 inches minimum terminal length, to-226ac joint electronic device engineering council/jedec/case outline designation, 0.165 inches maximum overall width

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Overall Length: 0.205 inches maximum
Terminal Length: 0.500 inches minimum
Overall Height: 0.210 inches maximum
Overall Width: 0.165 inches maximum
Joint Electronic Device Engineering Council/Jedec/Case Outline Designation: to-226ac
Mounting Method: terminal
Voltage Rating In Volts Per Characteristic: 30.0 nominal reverse breakdown voltage, instantaneous
Capacitance Rating In Picofarads: 6.8 nominal
Material: plastic inclosure
Material: silicon semiconductor
Terminal Type And Quantity: 2 uninsulated wire lead

Replaces National Stock Numbers

Below is a list of NSNs that have been officially superseded by this NSN:

NSN	Name	Date
5961-01-032-0470	No Name Available	08/01/1996

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
A2N20001326	Diode Semiconductor Device
CR202101	Diode Semiconductor Device
MV2101	Diode Semiconductor Device
MV2101G	Diode Semiconductor Device

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5961-00-434-3024?

The FSCG of the NSN 5961-00-434-3024 is 5961

Does the NSN 5961-00-434-3024 have a Schedule B code assigned?

Yes, the Schedule B code is 8541100070

Does NSN 5961-00-434-3024 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5961-00-434-3024 contain precious materials?

Item does not contain precious metal.

Does NSN 5961-00-434-3024 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5961-00-434-3024 was assigned to the Federal Catalog?

It was assigned 51 years ago, on Sun, May 26, 1974
